Technical Specifications

Size and Weight

• Height: 2.06 cm (0.8”)
• Width: 24.4 cm (9.5”)
• Depth: 16.2 cm (6.3”)
• Weight: 900 g (2 lbs.)

Major Capabilities

• Texas Instruments OMAP4460 1.2GHz Mobile Processor, Dual-core ARM® Cortex™-A9
• 32 GB internal SD card for firmware and storage
• 2GB Low Power DDR2 SDRAM
• 22.86 cm x 7.62 cm (9” x 3.8”) Multi-touch capacitive touch screen over a 1024 x 600
• 18 cm (7”) diagonal LCD screen
• HDMI output for external display (no audio)
• 18 or 32 Braille display cells with cursor routing buttons (1 button per cell)
• 8MP camera with LED based lighting.
• Wi-Fi 802.11 b/g/n
• Bluetooth 4.0 (dual mode: BLE and classic)

GPS

• High Speed USB 2.0 slave for PC connectivity and battery recharge
• High Speed USB 2.0 host port
• Audio Codec with volume control
• Internal Omni Directional MEMS type Microphone
• Internal stereo 1W Speakers (two speakers)
• Audio output connector for headphones or external speaker
• Audio input connector for external microphone or stereo recording (line-in)
• Integrated Battery Charger
• Rechargeable and user replaceable 5100mAh Lithium-Polymer Battery with thermistor and internal gas gauge

• Real Time Clock with battery backup
• Vibration device
• Sensors
• 3D Accelerometer
• 3D Gyroscope
• 3D Electronic compass
• Power requirement: +5VDC, 1.5A
• Battery: Li-Polymer 3.7V nominal, 5100mAh, in operation charge time of 12 hours

Environmental Conditions

This product meets EMC standards of all targeted countries. EMC consists of the limitation of radiated electromagnetic emissions from the unit and immunity of the product against external electromagnetic field and electrostatic discharge.

• Operating temperature range: 5 to 40 degrees Celsius
• Battery charging temperature range: 5 to 40 degrees Celsius
• Storage temperature: -20 to 60 degrees Celsius
• Operating humidity: 5% to 90% (non-condensing)
• First certified Braille Tablet providing Play Store access
• Storage humidity: 5% to 95% (non-condensing)
